PeakWay Pump
1 / 5
| EVI Air to Water Heat Pump (Heating and Cooling, Monoblock Type) | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Category | Parameters | Mode | Unit | MG-03KFXLR | MG-03KFXLR | MG-05KFXLR | MG-05KFXLR/380V | MG-10KFXLR | MG-20KFXLR |
| Heating Performance | Input Power | Heating | KW | 2.03 | 2.29 | 3.49 | 4.09 | 8.24 | 14.2 |
| Capacity | Heating | KW | 8.1 | 9.1 | 14 | 16.4 | 32.8 | 57.2 | |
| COP | Heating | - | 3.99 | 3.97 | 4.01 | 4.01 | 3.98 | 4.03 | |
| Current | Heating | A | 10.2 | 4.5 | 15.9 | 7.5 | 14.5 | 26 | |
| Water Flow | Heating | L/h | 2000 | 2200 | 3408 | 4000 | 8000 | 13800 | |
| Cooling Performance | Input Power | Cooling | KW | 2.32 | 2.62 | 4.01 | 4.71 | 9.42 | 15.9 |
| Capacity | Cooling | KW | 6.3 | 7.1 | 11 | 12.8 | 25.6 | 43.8 | |
| EER | Cooling | - | 2.72 | 2.71 | 2.74 | 2.72 | 2.72 | 2.75 | |
| Current | Cooling | A | 10.70 | 4.80 | 12.50 | 8.00 | 16.00 | 28.00 | |
| Water Flow | Cooling | L/h | 1400 | 1600 | 2386 | 2800 | 5600 | 10200 | |
| Noise Level | - | dB(A) | 50 | 50 | 60 | 60 | 65 | 75 | |
| Refrigerant | - | - | R407C | ||||||
| Compressor Type | - | - | Copeland Scroll Compressor | ||||||
